The VICI DBS ® HP Plus Tower produces nitrogen by utilizing a combination of filtration and pressure swing adsorption (PSA) technology. Standard compressed air is filtered by high efficiency coalescing filters to remove all contaminants down to 5 micron. For ultra sensitive applications such as GC carrier and make-up gas, units also include the additional heated catalyst module to ensure hydrocarbons are removed to
FEATURES
▪︎ Produces a continuous supply of high purity nitrogen
▪︎ On-demand supply 24/7
▪︎ Flow rate: 200 to 4000 mL/min
▪︎ Purity: up to +99.999% &
▪︎ Pressure: up to 5 barg (75 psig)
▪︎ Proprietary carbon molecular sieve technology
▪︎ Easy to install, operate and maintain
Benefits
▪︎ Eliminates dangerous high pressure cylinders helping to keep your employees safer
▪︎ Removes the logistics, inconvenience, downtime and costs of a cylinder system
▪︎ Flow capacity to match your specific instrument demands
▪︎ Ideal for all GC applications - stable baseline with increased sensitivity and repeatability
▪︎ Meets and exceeds the requirements for the most demanding GC applications
▪︎ Superior air purification with long life catalyst technology
▪︎ Peace of mind
▪︎ Improve your laboratory work flow and productivity
Applications
GC APPLICATIONS
▪︎ GC carrier and make-up gas
▪︎ ECD
▪︎ ELSD
▪︎ Sheath gas
▪︎ TGA & DSC
▪︎ Incubators
Technical specifications
| Models & Specs | HP Plus 500 | HP Plus 750 | HP Plus 1300 | HP Plus 4000 |
|---|---|---|---|---|
| Flow mL/min | 500 | 750 | 1300 | 4000 |
| Purity | +99.999% | +99.99% | +99% | |
| Hydrocarbon purity (measured as methane) | n/a | |||
| Dewpoint | -50 °C (-58 °F) | |||
| Outlet pressure barg (psig) | up to 5 max (75) | |||
| Inlet pressure barg (psig) | 7 to 10 (100 to 160) | |||
| Actual inlet air requirement litres - at 8 barg | 11 | 12 | 16 | 24 |
| Recommended compressor air inlet - at 8 barg | 22 | 24 | 32 | 48 |
| Pressure drop barg (psig) | 1.5 (22) | |||
| Inlet air quality | Clean dry compressed air ISO8573-1:2010 Class 1.2.1 | |||
| Technology | Carbon molecular sieve | |||
| Warm up time (minutes) | 60 | |||
| LED indicators | Power on/off, system ready, errors | |||
| Electricity supply | 110-120V 60Hz / 220-240V 50Hz | |||
| Power consumption (watts) | 12 | |||
| Noise level | minimal | |||
| Dimensions mm (in) | 140W x 490H x 630D (13.7W x 29H x 13.7D) | |||
| Weight kg (lbs) | 15 (17.6) | |||
| Shipping dimensions mm (in) | 770W x 590H x 410D (30.3W x 16.1H x 23.2D) | |||
| Shipping weight kg (lbs) | 20 (44) | |||
| Operating temp °C (°F) | 15 to 35 (59 to 95) | |||
| Inlet connection | 1/4” Compression | |||
| Outlet connection | 1/8" Compression | |||
| Certification | CE, FCC, MET (UL and CSA compliant) | |||
| Models & Specs | HP Plus 200 HC | HP Plus 500 HC | HP Plus 750 HC | HP Plus 1300 HC | HP Plus 4000 HC |
|---|---|---|---|---|---|
| Flow mL/min | 200 | 500 | 750 | 1300 | 4000 |
| Purity | +99.999% | +99.99% | +99% | ||
| Hydrocarbon purity (measured as methane) | 0.1 ppm | ||||
| Dewpoint | -50 °C (-58 °F) | ||||
| Outlet pressure barg (psig) | up to 5 max (75) | ||||
| Inlet pressure barg (psig) | 7 to 10 (100 to 160) | ||||
| Actual inlet air requirement litres - at 8 barg | 11 | 11 | 12 | 16 | 24 |
| Recommended compressor air inlet - at 8 barg | 22 | 22 | 24 | 32 | 48 |
| Pressure drop barg (psig) | 1.5 (22) | ||||
| Inlet air quality | Clean dry compressed air ISO8573-1:2010 Class 1.2.1 | ||||
| Technology | Carbon molecular sieve | ||||
| Warm up time (minutes) | 60 | ||||
| LED indicators | Power on/off, system ready, errors | ||||
| Electricity supply | 110-120V 60Hz / 220-240V 50Hz | ||||
| Power consumption (watts) | 270 | ||||
| Noise level | minimal | ||||
| Dimensions mm (in) | 140W x 490H x 630D (13.7W x 29H x 13.7D) | ||||
| Weight kg (lbs) | 17 (44) | ||||
| Shipping dimensions mm (in) | 770W x 590H x 410D (30.3W x 16.1H x 23.2D) | ||||
| Shipping weight kg (lbs) | 22 (49) | ||||
| Operating temp °C (°F) | 15 to 35 (59 to 95) | ||||
| Inlet connection | 1/4” Compression | ||||
| Outlet connection | 1/8" Compression | ||||
| Certification | CE, FCC, MET (UL and CSA compliant) | ||||
